PIPER AIRCRAFT, INC.
PA-28-161, WARRIOR III
MAINTENANCE MANUAL
PAGE 4
Nov 30/06
3F18
33-40-00
Strobe Light Connections
Figure 1 (Sheet 1 of 2)
GND-BLK
TRIGGER
2 (-)
1 (+)
POWER
1
L4C20
TAIL
2
WINGWING
3 4
POWER SUPPLY
SEE VIEW A
SEE VIEW B
*
NO JUMPER IN S/N’S 2842001 THRU 2842063
*
36879 AS
104296 K
3 21
GND
VIEW A
L4C20
WHT
RED
123
STROBE
CABLE
BLK (SHIELDED)
VIEW B
STROBE
LIGHTS
OFF
L4B20
L4A20
TO DIMMER
TO GND
SWITCH CONNECTIONS
SWITCH FACE
