PIPER AIRCRAFT, INC.
PA-28-161, WARRIOR III
MAINTENANCE MANUAL
PAGE 2
Nov 30/06
3G10
34-10-00
AIRSPEED
INDICATOR (REF.)
ALTIMETER
(REF.)
ENCODER
(REF.)
STATIC LINE
PITOT LINE
PITOT
STATIC
PRIMARY FLIGHT DISPLAY (PFD) (REF.)
OPTIONAL AVIDYNE ENTEGRA INSTALLATION
UP
FWD
35493 BX
Pitot / Static System Installation
Figure 1 (Sheet 2 of 2)
Effectivity
with Avidyne Entegra
