PIPER AIRCRAFT, INC.
PA-28-161, WARRIOR III
MAINTENANCE MANUAL
PAGE 2
Nov 30/06
3I18
37-00-00
CHART 1 (Sheet 1 of 2)
TROUBLESHOOTING VACUUM SYSTEM
Trouble Cause Remedy
No vacuum gauge indication Filter clogged or dirty. Clean or replace filter.
at instrument.
Line from gyro to filter restricted. Check line.
No vacuum gauge indication Faulty gauge or malfunctioning Replace gauge or pump
at gauge or pump. pump.
Low vacuum system pressure. Filter dirty. Clean or replace filter.
Vacuum regulator valve Adjust regulator valve in
incorrectly adjusted. accordance with
adjustments in this section.
Line from gyros to filter restricted. Repair line.
Line from pump to gyros leaking. Check all lines and fittings.
Replace or tighten
as necessary.
Normal pressure indication but Faulty instrument. Replace instrument.
sluggish operation of instruments.
High system pressure. Vacuum regulator incorrectly Adjust regulator.
adjusted.
Vacuum regulator sticking Clean screen and check
or dirty screen. operation of regulator.
Regulator cannot be adjusted Lines leaking. Check all lines and fittings.
to produce correct pressure. Replace or tighten as
necessary.
Vacuum pump malfunctioning. Replace pump.
Vacuum correct on ground, but Vacuum pump malfunctioning. Replace pump.
will not maintain pressure at
altitude. Regulator sticky. Clean regulator.
Vacuum correct, but pilot reports Regulator sticky. Clean regulator.
pressure erratic or shows
complete loss in fight. Oil in pump due to leaky Replace pump.
engine seal or cleaning fluid
blown into pump while
cleaning engine.
Pressure can only be maintained Leak in system. Check all lines and fittings.
at full throttle on ground. Replace or tighten as
necessary.
Worn pump. Replace pump.
Stuck regulator. Clean or replace regulator.
