User’s Manual of GS-5220 LCD Series
105
IPv6 Address Provide the IP address of this Managed Switch. An IPv6 address
is in 128-bit records represented as eight fields of up to four
hexadecimal digits with a colon separating each field (:).
Mask Length The IPv6 network mask, in number of bits (prefix length). Valid
values are between 1 and 128 bits for an IPv6 address.
• IP Routes Delete Select this option to delete an existing IP route.
Network
The destination IP network or host address of this route. Valid
format is dotted decimal notation or a valid IPv6 notation. A
default route can use the value 0.0.0.0 or IPv6 :: notation.
Mask Length
The destination IP network or host mask, in number of bits
(prefix length).
Gateway The IP address of the IP gateway. Valid format is dotted decimal
notation or a valid IPv6 notation. Gateway and Network must be
of the same type.
Next Hop VLAN The VLAN ID (VID) of the specific IPv6 interface associated with
the gateway.
Buttons
: Click to add a new IP interface. A maximum of 128 interfaces are supported.
: Click to add a new IP route. A maximum of 32 routes are supported.
: Click to apply changes.
: Click to undo any changes made locally and revert to previously saved values.
