User’s Manual of GS-5220 LCD Series
290
• IGMPv2/MLDv1 Reports
Received
The number of Received IGMPv2 Joins and MLDv1 Reports,
respectively.
• IGMPv3/MLDv2 Reports
Received
The number of Received IGMPv1 Joins and MLDv2 Reports,
respectively.
• IGMPv2/MLDv1 Leaves
Received
The number of Received IGMPv2 Leaves and MLDv1 Dones,
respectively.
Buttons
: Click to refresh the page immediately.
: Clears all Statistics counters.
Auto-refresh : Automatic refresh occurs every 3 seconds.
4.8.18 MVR Groups Information
Entries in the MVR Group Table are shown on this page. The MVR Group Table is sorted first by VLAN ID, and
then by group.
Each page shows up to 99 entries from the MVR Group table, default being 20, selected through the "entries per
page" input field. When first visited, the web page will show the first 20 entries from the beginning of the MVR
Group Table.
The "Start from VLAN", and "group" input fields allow the user to select the starting point in the MVR Group
Table. The MVR Groups Information screen in Figure 4-8-21 appears.
