User’s Manual of GS-5220 LCD Series
272
• Port Members
Ports under this group.
Buttons
Auto-refresh : Automatic refresh occurs every 3 seconds.
: Refreshes the displayed table starting from the input fields.
: Updates the table, starting with the first entry in the IGMP Group Table.
: Updates the table, starting with the entry after the last entry currently displayed.
4.8.9 IGMPv3 Information
Entries in the IGMP SSM Information Table are shown on this page. The IGMP SSM Information Table is sorted
first by VLAN ID, then by group, and then by Port No. Diffrent source addresses belong to the same group are
treated as single entry.
Each page shows up to 99 entries from the IGMP SSM (Source Specific Multicast) Information table, default
being 20, selected through the "entries per page" input field. When first visited, the web page will show the first
20 entries from the beginning of the IGMP SSM Information Table.
The "Start from VLAN", and "Group" input fields allow the user to select the starting point in the IGMP SSM
Information Table. The IGMPv3 Information screen in Figure 4-8-12 appears.
