User’s Manual of GS-5220 LCD Series
279
Port Group Filtering Configuration screen in Figure 4-8-15 appears.
Figure 4-8-15: MLD Snooping Port Group Filtering Configuration Page Screenshot
The page includes the following fields:
Object Description
• Port
The logical port for the settings.
• Filtering Group
Select the IPMC Profile as the filtering condition for the specific port.
Summary about the designated profile will be shown by clicking the
view button.
Buttons
: Click to apply changes
: Click to undo any changes made locally and revert to previously saved values.
4.8.13 MLD Snooping Status
This page provides MLD Snooping status. The IGMP Snooping Status screen in Figure 4-8-16 appears.
