User’s Manual of GS-5220 LCD Series
478
• Auto-negotiation
status
Auto-negotiation status identifies if auto-negotiation is currently
enabled at the link partner. If Auto-negotiation is supported and
Auto-negotiation status is disabled, the 802.3 PMD operating mode
will be determined the operational MAU type field value rather than by
auto-negotiation.
• Auto-negotiation
Capabilities
Auto-negotiation Capabilities shows the link partners MAC/PHY
capabilities.
Buttons
: Click to refresh the page immediately.
Auto-refresh
: Check this box to refresh the page automatically. Automatic refresh occurs every 3
seconds.
4.14.5 Neighbor
This page provides a status overview for all LLDP neighbors. The displayed table contains a row for each port on
which an LLDP neighbor is detected. The LLDP Neighbor Information screen in Figure 4-14-4 appears.
Figure 4-14-4: LLDP Neighbor Information Page Screenshot
