User’s Manual of GS-5220 LCD Series
443
• Port Mode
Configuration
Indicates the DHCP snooping port mode. Possible port modes are:
Trusted: Configures the port as trusted sources of the DHCP
message.
Untrusted: Configures the port as untrusted sources of the DHCP
message.
Buttons
: Click to apply changes
: Click to undo any changes made locally and revert to previously saved values.
4.12.9 Snooping Table
This page display the dynamic IP assigned information after DHCP Snooping mode is disabled. All DHCP clients obtained the
dynamic IP address from the DHCP server will be listed in this table except for local VLAN interface IP addresses. Entries in
the Dynamic DHCP snooping Table are shown on this page
. The Dynamic DHCP Snooping Table screen in Figure
4-12-9 appears.
Figure 4-12-9: Dynamic DHCP Snooping Table Screen Page Screenshot
