User’s Manual of GS-5220 LCD Series
322
• Enable
Controls whether the storm control is enabled on this switch port.
• Rate
Controls the rate for the storm control. The default value is 500. This
value is restricted to 100-1000000 when the "Unit" is "kbps" or "fps",
and it is restricted to 1-13200 when the "Unit" is "Mbps" or "kfps”.
• Unit
Controls the unit of measure for the storm control rate as kbps, Mbps,
fps or kfps . The default value is "kbps".
Buttons
: Click to apply changes
: Click to undo any changes made locally and revert to previously saved values.
4.9.14 WRED
This page allows you to configure the Random Early Detection (RED) settings for queue 0 to 5. RED cannot be
applied to queue 6 and 7. Through different RED configuration for the queues (QoS classes) it is possible to
obtain Weighted Random Early Detection (WRED) operation between queues. The settings are global for all
ports in the switch. The WRED screen in Figure 4-9-16 appears.
Figure 4-9-16 WRED Page Screenshot
