2. INSTALLATION
This section describes the hardware features and installation of the Managed Switch on the desktop or rack
mount. For easier management and control of the Managed Switch, familiarize yourself with its display
indicators, and ports. Front panel illustrations in this chapter display the unit LED indicators. Before connecting
any network device to the Managed Switch, please read this chapter completely.
2.1 Hardware Description
2.1.1 Switch Front Panel
The front panel provides a simple interface monitoring the Managed Switch. Figures 2-1-1 to 2-1-12 show the
front panels of the Managed Switches.
GS-5220-16T2XV Front Panel
Figure 2-1-1: Front Panel of GS-5220-16T2XV
GS-5220-16T2XVR Front Panel
Figure 2-1-2: Front Panel of GS-5220-16T2XVR
