User’s Manual of GS-5220 LCD Series
451
• IP Address
Allowed Source IP address in ARP request packets.
Buttons
: Click to add a new entry to the Static ARP Inspection table.
: Click to apply changes
: Click to undo any changes made locally and revert to previously saved values.
4.12.14 Dynamic ARP Inspection Table
Entries in the Dynamic ARP Inspection Table are shown on this page. The Dynamic ARP Inspection Table contains
up to 1024 entries, and is sorted first by port, then by VLAN ID, then by MAC address, and then by IP address.
The Dynamic ARP Inspection Table screen in Figure 4-12-14 appears.
Figure 4-12-14: Dynamic ARP Inspection Table Screenshot
Navigating the ARP Inspection Table
Each page shows up to 99 entries from the Dynamic ARP Inspection table, default being 20, selected through the
"entries per Page" input field. When first visited, the web page will show the first 20 entries from the beginning
of the Dynamic ARP Inspection Table.
To Next Page
