User’s Manual of GS-5220 LCD Series
132
• E-mail From
Type the sender’s e-mail address. This address is used for reply e-mails.
• E-mail Subject
Type the subject/title of the e-mail.
• E-mail 1 To
Type the receiver’s e-mail address.
• E-mail 2 To
Buttons
: Send a test mail to mail server to check whether this account is available or not.
: Click to save changes.
: Click to undo any changes made locally and revert to previously saved values.
4.2.16 Web Firmware Upgrade
This page facilitates an update of the firmware controlling the switch. The Web Firmware Upgrade screen in
Figure 4-2-19 appears.
Figure 4-2-19: Web Firmware Upgrade Page Screenshot
To open Firmware Upgrade screen, perform the following:
1. Click System -> Web Firmware Upgrade.
2. The Firmware Upgrade screen is displayed as in Figure 4-2-19.
3. Click the “
“button of the Main page; the system would pop up the file selection menu to choose
firmware.
