User’s Manual of GS-5220 LCD Series
534
4.20.2 ONVIF Device List
This page provides an overview of ONVIF Device entries. Each page shows up to 10 entries from the ONVIF
Device List table, default being 10, selected through the "entries per page" input field. When first visited, the
web page will show the first 10 entries from the beginning of the ONVIF Device List table; screen in Figure 4-20-2
appears.
Figure 4-20-2: ONVIF Device List Page Screenshot
The page includes the following fields:
Object Description
• Login(Optional)
Allows for filling one set of User name and Password.
• Port
This is the logical port number for this row.
• Status
Red: The ONVIF device is not active.
Green: The ONVIF device is active.The ONVIF Device’s Type of the
entry.
• Device Type
The ONVIF Device’s Type of the entry.
• Device Name
The ONVIF Device’s Name of the entry.
