User’s Manual of GS-5220 LCD Series
259
• Profile Description
Additional description, which is composed of at maximum 64
alphabetic and numeric characters, about the profile.
No blank or space characters are permitted as part of description. Use
"_" or "-" to separate the description sentence.
• Rule
When the profile is created, click the edit button to enter the rule
setting page of the designated profile. Summary about the designated
profile will be shown by clicking the view button. You can manage or
inspect the rules of the designated profile by using the following
buttons:
: List the rules associated with the designated profile.
: Adjust the rules associated with the designated profile.
Buttons
: Click to add new IPMC profile. Specify the name and configure the new entry. Click
"Save”.
: Click to apply changes
: Click to undo any changes made locally and revert to previously saved values.
4.8.3 Address Entry
This page provides address range settings used in IPMC profile. The address entry is used to specify the address
range that will be associated with
IPMC Profile. It is allowed to create at maximum 128 address entries in the
system.
The Profile Table screen in Figure 4-8-6 appears.
