User’s Manual of GS-5220 LCD Series
503
4.16.6 PoE Status
This page allows the user to inspect the total power consumption, total power reserved and current status for all
PoE ports. The screen in Figure 4-16-5 appears.
Figure 4-16-5:PoE Status Screenshot
The page includes the following fields:
Object Description
• Sequential Power On
Displays the current sequential power on mode.
• System Power Budget
Displays the maximum PoE power budget.
• Operation Mode
Displays the current PoE operation mode.
