User’s Manual of GS-5220 LCD Series
527
4.18.8 RMON Statistics Status
This page provides an overview of RMON Statistics entries. Each page shows up to 99 entries from the Statistics
table, default being 20, selected through the "entries per page" input field. When first visited, the web page will
show the first 20 entries from the beginning of the Statistics table. The first displayed will be the one with the
lowest ID found in the Statistics table; screen in Figure 4-18-9 appears.
Figure 4-18-9: RMON Statistics Status Overview Page Screenshot
The page includes the following fields:
Object Description
• ID
Indicates the index of Statistics entry.
• Data Source (ifIndex)
The port ID which wants to be monitored.
• Drop
The total number of events in which packets were dropped by the
probe due to lack of resources.
• Octets
The total number of octets of data (including those in bad packets)
received on the network.
• Pkts
The total number of packets (including bad packets, broadcast packets,
and multicast packets) received.
• Broadcast
The total number of good packets received that were directed to the
broadcast address.
