User’s Manual of GS-5220 LCD Series
318
• IPv6
Protocol IP protocol number: (0-255, TCP or UDP) or 'Any'
Source IP IPv6 source address: (a.b.c.d) or 'Any', 32 LS bits
DSCP Diffserv Code Point value(DSCP): It can be specific value, range of
value or 'Any'. DSCP values are in the range 0-63 including BE, CS1-CS7,
EF or AF11-AF43
Sport Source TCP/UDP port:(0-65535) or 'Any', specific or port range
applicable for IP protocol UDP/TCP
Dport Destination TCP/UDP port:(0-65535) or 'Any', specific or port
range applicable for IP protocol UDP/TCP
• Action Parameters
Class QoS class: (0-7) or 'Default'.
DPL Valid Drop Precedence Level can be (0-3) or 'Default'.
DSCP Valid DSCP value can be (0-63, BE, CS1-CS7, EF or AF11-AF43) or
'Default'.
'Default' means that the default classified value is not modified by this
QCE.
Buttons
: Click to apply changes
: Click to undo any changes made locally and revert to previously saved values
: Return to the previous page without saving the configuration change
4.9.12 QCL Status
This page shows the QCL status by different QCL users. Each row describes the QCE that is defined. It is a conflict
if a specific QCE is not applied to the hardware due to hardware limitations. The maximum number of QCEs is
To Next Page
