User’s Manual of GS-5220 LCD Series
500
Buttons
: Click to apply changes
: Click to undo any changes made locally and revert to previously saved values.
4.16.5 Port Configuration
This section allows the user to inspect and configure the current PoE port settings as Figure 4-16-4 shows.
Figure 4-16-4: Power over Ethernet Configuration Screenshot
The page includes the following fields:
Object Description
• PoE Mode
There are three modes for PoE mode.
Enable: enable PoE function..
Disable: disable PoE function.
Schedule: enable PoE function in schedule mode.
