User’s Manual of GS-5220 LCD Series
97
4.1 Main Web Page
The Managed Switch provides a Web-based browser interface for configuring and managing it. This interface
allows you to access the Managed Switch using the Web browser of your choice. This chapter describes how to
use the Managed Switch’s Web browser interface to configure and manage it.
Figure 4-1-4: Web Main Page
Panel Display
The web agent displays an image of the Managed Switch’s ports. The Mode can be set to display different
information for the ports, including Link up or Link down. Clicking on the image of a port opens the Port
Statistics page.
The port status are illustrated as follows:
State Disabled Down Link
RJ45 Ports
SFP Ports
Help Button
Main Screen
Copper Port Link
SFP/SFP+ Port Link
Main Functions Menu
To Next Page
