User’s Manual of GS-5220 LCD Series
521
4.18.4 RMON Event Status
This page provides an overview of RMON Event table entries. Each page shows up to 99 entries from the Event
table, default being 20, selected through the "entries per page" input field. When first visited, the web page will
show the first 20 entries from the beginning of the Event table. The first displayed will be the one with the
lowest Event Index and Log Index found in the Event table; screen in Figure 4-18-5 appears.
Figure 4-18-5: RMON Event Overview Page Screenshot
The page includes the following fields:
Object Description
• Event Index
Indicates the index of the event entry.
• Log Index
Indicates the index of the log entry.
• Logtime
Indicates Event log time.
• Log Description
Indicates the Event description.
Buttons
: Click to refresh the page immediately.
Auto-refresh
: Check this box to refresh the page automatically. Automatic refresh occurs every 3
seconds.
