User’s Manual of GS-5220 LCD Series
480
4.14.6 Port Statistics
This page provides an overview of all LLDP traffic. Two types of counters are shown. Global counters are
counters that refer to the whole switch, while local counters refers to counters for the currently selected switch.
The LLDP Statistics screen in Figure 4-14-5 appears.
Figure 4-14-5: LLDP Statistics Page Screenshot
The page includes the following fields:
Global Counters
Object Description
• Neighbor entries
were last changed
It also shows the time when the last entry was last deleted or added. It
also shows the time elapsed since the last change was detected.
• Total Neighbors
Entries Added
Shows the number of new entries added since switch reboot.
