User’s Manual of GS-5220 LCD Series
524
4.18.6 RMON History Status
This page provides an detail of RMON history entries; screen in Figure 4-18-7 appears.
Figure 4-18-7: RMON History Overview Page Screenshot
The page includes the following fields:
Object Description
• History Index Indicates the index of History control entry.
• Sample Index Indicates the index of the data entry associated with the control entry.
• Sample Start The value of sysUpTime at the start of the interval over which this
sample was measured.
• Drop The total number of events in which packets were dropped by the
probe due to lack of resources.
• Octets The total number of octets of data (including those in bad packets)
received on the network.
• Pkts The total number of packets (including bad packets, broadcast packets,
and multicast packets) received.
• Broadcast The total number of good packets received that were directed to the
broadcast address.
• Multicast The total number of good packets received that were directed to a
multicast address.
