User’s Manual of GS-5220 LCD Series
281
• V2 Reports Received
The number of Received V2 Reports.
• V1 Leave Received
The number of Received V1 Leaves.
• Router Port
Display which ports act as router ports. A router port is a port on the
Ethernet switch that leads towards the Layer 3 multicast device or MLD
querier.
Static denotes the specific port is configured to be a router port.
Dynamic denotes the specific port is learnt to be a router port.
Both denote the specific port is configured or learnt to be a router port.
• Port
Switch port number.
• Status
Indicates whether specific port is a router port or not.
Buttons
: Click to refresh the page immediately.
: Clears all Statistics counters.
Auto-refresh : Automatic refresh occurs every 3 seconds.
4.8.14 MLD Group Information
Entries in the MLD Group Table are shown on this page. The MLD Group Table is sorted first by VLAN ID, and
then by group.
Each page shows up to 99 entries from the MLD Group table, default being 20, selected through the "entries per
page" input field. When first visited, the web page will show the first 20 entries from the beginning of the MLD
Group Table.
The "Start from VLAN", and "group" input fields allow the user to select the starting point in the MLD Group
Table. The MLD Groups Information screen in Figure 4-8-17 appears.
