User’s Manual of GS-5220 LCD Series
183
The page includes the following fields:
Object Description
• Port
The switch port number.
• LACP
'Yes' means that LACP is enabled and the port link is up. 'No' means
that LACP is not enabled or that the port link is down. 'Backup' means
that the port could not join the aggregation group but will join if other
port leaves. Meanwhile it's LACP status is disabled.
• Key
The key assigned to this port. Only ports with the same key can
aggregate together.
• Aggr ID
The Aggregation ID assigned to this aggregation group.
• Partner System ID
The partner’s System ID (MAC address).
• Partner Port
The partner’s port number connected to this port.
• Partner Priority
The partner's port priority.
Buttons
: Click to refresh the page immediately.
Auto-refresh
: Automatic refresh occurs every 3 seconds.
4.5.5 LACP Port Statistics
This page provides an overview of LACP statistics for all ports. The LACP Port Statistics screen in Figure 4-5-7
appears.
