User’s Manual of GS-5220 LCD Series
123
Figure 4-2-13: DHCP Relay Statistics Page Screenshot
The page includes the following fields:
Server Statistics
Object Description
• Transmit to Server
The packets number that relayed from client to server.
• Transmit Error
The packets number that erroneously sent packets to clients.
• Receive from Server
The packets number that received packets from server.
• Receive Missing
Agent Option
The packets number that received packets without agent information
options.
• Receive Missing
Circuit ID
The packets number that received packets whose the Circuit ID option
was missing.
• Receive Missing
Remote ID
The packets number that received packets whose Remote ID option
was missing.
• Receive Bad Circuit
ID
The packets number whose the Circuit ID option did not match known
circuit ID.
Receive Bad Remote ID The packets number whose the Remote ID option did not match known
Remote ID.
