User’s Manual of GS-5220 LCD Series
134
Figure 4-2-20: TFTP Firmware Update Page Screenshot
The page includes the following fields:
Object Description
• TFTP Server IP
Fill in your TFTP server IP address.
• Firmware File Name
The name of firmware image.
(Maximum length: 24 characters)
Buttons
: Click to upgrade firmware.
DO NOT Power OFF the Managed Switch until the update progress is complete.
Do not quit the Firmware Upgrade page without pressing the “OK” button after
the image is loaded. Or the system won’t apply the new firmware. User has to
repeat the firmware upgrade processes.
