Planet GS-5220-24T4XVR - Page 169

User’s Manual of GS-5220 LCD Series
169
Figure 4-4-4: SFP Module Information for Switch Page Screenshot
The page includes the following fields:
Object Description
• Type
Display the type of current SFP module; the possible types are:
 10GBASE-SR
 10GBASE-LR
 1000BASE-SX
 1000BASE-LX
 100BASE-FX
• Speed
Display the speed of current SFP module; the speed value or
description is got from the SFP module. Different vendors SFP modules
might show different speed information.
• Wave Length (nm)
Display the wavelength of current SFP module; the wavelength value is
got from the SFP module. Use this column to check if the wavelength
values of two nodes are matched while the fiber connection failed.
• Distance (m)
Display the support distance of current SFP module; the distance value
is got from the SFP module.
