User’s Manual of GS-5220 LCD Series
180
Figure 4-5-4 : LACP Port Configuration Page Screenshot
The page includes the following fields:
Object Description
• Port
The switch port number.
• LACP Enabled
Controls whether LACP is enabled on this switch port. LACP will form an
aggregation when 2 or more ports are connected to the same partner.
• Key
The Key value incurred by the port, range 1-65535 . The Auto setting
will set the key as appropriate by the physical link speed, 10Mb = 1,
100Mb = 2, 1Gb = 3. Using the Specific setting, a user-defined value can
be entered. Ports with the same Key value can participate in the same
aggregation group, while ports with different keys cannot.
The default setting is “Auto”
