User’s Manual of GS-5220 LCD Series
245
The page includes the following fields:
Configuration Identification
Object Description
• Configuration Name
The name identifying the VLAN to MSTI mapping. Bridges must share
the name and revision (see below), as well as the VLAN-to-MSTI
mapping configuration in order to share spanning trees for MSTI's.
(Intra-region). The name is at most 32 characters.
• Configuration
Revision
The revision of the MSTI configuration named above. This must be an
integer between 0 and 65535.
MSTI Mapping
Object Description
• MSTI
The bridge instance. The CIST is not available for explicit mapping, as it
will receive the VLANs not explicitly mapped.
• VLANs Mapped
The list of VLAN's mapped to the MSTI. The VLANs must be separated
with comma and/or space. A VLAN can only be mapped to one MSTI. A
unused MSTI should just be left empty. (I.e. not having any VLANs
mapped to it.)
Buttons
: Click to apply changes
: Click to undo any changes made locally and revert to previously saved values.
