User’s Manual of GS-5220 LCD Series
249
The page includes the following fields:
Object Description
• Port
The switch port number of the logical STP port.
• CIST Role
The current STP port role of the ICST port. The port role can be one of
the following values:
■ AlternatePort
■ BackupPort
■ RootPort
■ DesignatedPort
■ Disable
• CIST State
The current STP port state of the CIST port . The port state can be one
of the following values:
■ Disabled
■ Learning
■ Forwarding
• Uptime
The time since the bridge port was last initialized.
Buttons
: Click to refresh the page immediately.
Auto-refresh
: Check this box to refresh the page automatically. Automatic refresh occurs every 3
seconds
