User’s Manual of GS-5220 LCD Series
307
• Classify
Classification for a port have 4 different values.
Disable: No Ingress DSCP Classification.
DSCP=0: Classify if incoming (or translated if enabled) DSCP is 0.
Selected: Classify only selected DSCP for which classification is
enabled as specified in DSCP Translation window for the specific
DSCP.
All: Classify all DSCP.
• Egress
Port Egress Rewriting can be one of -
Disable: No Egress rewrite.
Enable: Rewrite enable without remapped.
Remap DP Unaware: DSCP from analyzer is remapped and frame
is remarked with remapped DSCP value. The remapped DSCP
value is always taken from the 'DSCP Translation->Egress Remap
DP0' table.
Remap DP Aware: DSCP from analyzer is remapped and frame is
remarked with remapped DSCP value. Depending on the DP level
of the frame, the remapped DSCP value is either taken from the
'DSCP Translation->Egress Remap DP0' table or from the 'DSCP
Translation->Egress Remap DP1' table.
Buttons
: Click to apply changes
: Click to undo any changes made locally and revert to previously saved values.
