User’s Manual of GS-5220 LCD Series
310
The page includes the following fields:
Object Description
• DSCP
Maximum number of supported DSCP values are 64 and valid DSCP
value ranges from 0 to 63.
• Ingress
Ingress side DSCP can be first translated to new DSCP before using the
DSCP for QoS class and DPL map.
There are two configuration parameters for DSCP Translation –
■ Translate
■ Classify
• Translate
DSCP at Ingress side can be translated to any of (0-63) DSCP values.
• Classify
Click to enable Classification at Ingress side.
• Egress
There is following configurable parameter for Egress side -
■ Remap
• Remap DP
Select the DSCP value from select menu to which you want to remap.
DSCP value ranges form 0 to 63.
Buttons
: Click to apply changes
: Click to undo any changes made locally and revert to previously saved values.
