User’s Manual of GS-5220 LCD Series
316
• Key Parameters
Key configuration are described as below:
■ DMAC Type Destination MAC type: possible values are
unicast(UC), multicast(MC), broadcast(BC) or 'Any'
■ SMAC Source MAC address: 24 MS bits (OUI) or 'Any'
■ Tag Value of Tag field can be 'Any', 'Untag' or 'Tag'
■ VID Valid value of VLAN ID can be any value in the range 1-4095
or 'Any'; user can enter either a specific value or a range of VIDs
■ PCP Priority Code Point: Valid value PCP are specific(0, 1, 2, 3, 4, 5,
6, 7) or range(0-1, 2-3, 4-5, 6-7, 0-3, 4-7) or 'Any'
■ DEI Drop Eligible Indicator: Valid value of DEI can be any of values
between 0, 1 or 'Any'
■ Frame Type Frame Type can have any of the following values
1. Any
2. Ethernet
3. LLC
4. SNAP
5. IPv4
6. IPv6
Note: all frame types are explained below.
• Any
Allow all types of frames.
• EtherType
Ethernet Type Valid Ethernet type can have value within 0x600-0xFFFF
or 'Any' but excluding 0x800(IPv4) and 0x86DD(IPv6), default value is
'Any'.
