User’s Manual of GS-5220 LCD Series
332
The page includes the following fields:
Object Description
• User
Indicates the ACL user.
• Ingress Port
Indicates the ingress port of the ACE. Possible values are:
■ All: The ACE will match all ingress port.
■ Port: The ACE will match a specific ingress port.
• Frame Type
Indicates the frame type of the ACE. Possible values are:
■ Any: The ACE will match any frame type.
■ EType: The ACE will match Ethernet Type frames. Note that
an Ethernet Type based ACE will not get matched by IP and
ARP frames.
■ ARP: The ACE will match ARP/RARP frames.
■ IPv4: The ACE will match all IPv4 frames.
■ IPv4/ICMP: The ACE will match IPv4 frames with ICMP
protocol.
■ IPv4/UDP: The ACE will match IPv4 frames with UDP
protocol.
■ IPv4/TCP: The ACE will match IPv4 frames with TCP protocol.
■ IPv4/Other: The ACE will match IPv4 frames, which are not
ICMP/UDP/TCP.
■ IPv6: The ACE will match all IPv6 standard frames.
