User’s Manual of GS-5220 LCD Series
344
• IP
Specify whether frames can hit the action according to their ARP/RARP
hardware address space (HRD) settings.
■ 0: ARP/RARP frames where the HLD is equal to Ethernet (1).
■ 1: ARP/RARP frames where the HLD is equal to Ethernet (1).
■ Any: Any value is allowed ("don't-care").
• Ethernet
Specify whether frames can hit the action according to their ARP/RARP
protocol address space (PRO) settings.
■ 0: ARP/RARP frames where the PRO is equal to IP (0x800).
■ 1: ARP/RARP frames where the PRO is equal to IP (0x800).
■ Any: Any value is allowed ("don't-care").
 IP Parameters
The IP parameters can be configured when Frame Type "IPv4" is selected.
Object Description
