User’s Manual of GS-5220 LCD Series
346
• IP Fragment
Specify the fragment offset settings for this ACE. This involves the
settings for the More Fragments (MF) bit and the Fragment Offset
(FRAG OFFSET) field for an IPv4 frame.
â– No: IPv4 frames where the MF bit is set or the FRAG OFFSET field
is greater than zero must not be able to match this entry.
â– Yes: IPv4 frames where the MF bit is set or the FRAG OFFSET field
is greater than zero must be able to match this entry.
â– Any: Any value is allowed ("don't-care").
• IP Option
Specify the options flag setting for this ACE.
â– No: IPv4 frames where the options flag is set must not be able to
match this entry.
â– Yes: IPv4 frames where the options flag is set must be able to
match this entry.
â– Any: Any value is allowed ("don't-care").
• SIP Filter
Specify the source IP filter for this ACE.
â– Any: No source IP filter is specified. (Source IP filter is
"don't-care".)
â– Host: Source IP filter is set to Host. Specify the source IP address
in the SIP Address field that appears.
â– Network: Source IP filter is set to Network. Specify the source IP
address and source IP mask in the SIP Address and SIP Mask fields
that appear.
• SIP Address
When "Host" or "Network" is selected for the source IP filter, you can
enter a specific SIP address in dotted decimal notation.
• SIP Mask
When "Network" is selected for the source IP filter, you can enter a
specific SIP mask in dotted decimal notation.
