User’s Manual of GS-5220 LCD Series
348
• Next Header Filter
Specify the IPv6 next header filter for this ACE.
â– Any: No IPv6 next header filter is specified ("don't-care").
â– Specific: If you want to filter a specific IPv6 next header filter
with this ACE, choose this value. A field for entering an IPv6 next
header filter appears.
â– ICMP: Select ICMP to filter IPv6 ICMP protocol frames. Extra
fields for defining ICMP parameters will appear. These fields are
explained later in this help file.
â– UDP: Select UDP to filter IPv6 UDP protocol frames. Extra fields
for defining UDP parameters will appear. These fields are
explained later in this help file.
â– TCP: Select TCP to filter IPv6 TCP protocol frames. Extra fields for
defining TCP parameters will appear. These fields are explained
later in this help file.
• Next Header Value
When "Specific" is selected for the IPv6 next header value, you can
enter a specific value. The allowed range is 0 to 255. A frame that hits
this ACE matches this IPv6 protocol value.
• SIP Filter
Specify the source IPv6 filter for this ACE.
â– Any: No source IPv6 filter is specified. (Source IPv6 filter is
"don't-care".)
â– Specific: Source IPv6 filter is set to Network. Specify the source
IPv6 address and source IPv6 mask in the SIP Address fields that
appear.
• SIP Address
When "Specific" is selected for the source IPv6 filter, you can enter a
specific SIPv6 address. The field only supported last 32 bits for IPv6
address.
