User’s Manual of GS-5220 LCD Series
460
• Tx Reinit
When a port is disabled, LLDP is disabled or the switch is rebooted a
LLDP shutdown frame is transmitted to the neighboring units, signaling
that the LLDP information isn't valid anymore. Tx Reinit controls the
amount of seconds between the shutdown frame and a new LLDP
initialization. Valid values are restricted to 1 - 10 seconds.
LLDP Port Configuration
The LLDP port settings relate to the switch, as reflected by the page header.
Object Description
• Port
The switch port number of the logical LLDP port.
• Mode
Select LLDP mode.
Rx only The switch will not send out LLDP information, but LLDP
information from neighbor units is analyzed.
Tx only The switch will drop LLDP information received from
neighbors, but will send out LLDP information.
Disabled The switch will not send out LLDP information, and will
drop LLDP information received from neighbors.
Enabled The switch will send out LLDP information, and will
analyze LLDP information received from neighbors.
