User’s Manual of GS-5220 LCD Series
51
Address Table 16K entries, automatic source address learning and aging
Shared Data Buffer 32M bits
Flow Control
IEEE 802.3x pause frame for full-duplex
Back pressure for half-duplex
Jumbo Frame 10K bytes
Reset Button
< 5 sec: System reboot
> 5 sec: Factory default
Dimensions (W x D x H) 440 x 300 x 56 mm, 1.25U height
Weight 4273g 4373g
LED
System:
SYS (Green)
AC/PWR (Green)
DC (Green) (GS-5220-16P2XVR Only)
Fan1/2/3 Alert (Red)
PoE PWR Alert (Red)
PoE Ethernet Interfaces (Port-1 to Port-16):
PoE-in-use (Orange)
Ethernet Interfaces (Port-1 to Port-16):
1000 LNK/ACT (Green), 10/100 LNK/ACT (Orange)
1/10G SFP+ Interfaces (Port-17 to Port-18):
1G (Green), 10G (Orange)
Power Consumption Max. 271 watts/924.69 BTU
AC: Max. 271 watts/924.69 BTU
DC: Max. 36.6 watts/124.88 BTU
Power Requirements – AC AC 100~240V, 50/60Hz, 2.6A
Power Requirements – DC -- DC 36~60V, 2A
ESD Protection 6KV DC
Fan 3 smart fans
Power over Ethernet
PoE Standard IEEE 802.3af/802.3at PoE PSE
PoE Power Supply Type End-span
PoE Power Output Per port 53V DC, 36 watts (max.)
Power Pin Assignment End-span: 1/2(-), 3/6(+)
PoE Power Budget 220 watts (max.)
PoE Ability PD @ 7 watts 16 units
PoE Ability PD @ 15 watts 14 units
