2.40
9850045 R01 - 2020-2021 RANGER 1000 Service Manual
© Copyright Polaris Inc.
4. Push down on the alignment tabs until an audible
click is heard.
IMPORTANT
Ensure the airbox lid, seal and seal gland are free from
dirt and debris when assembling the lid to the box.
ENGINE CRANKCASE BREATHER HOSE
INSPECTION
The engine crankcase is equipped with a breather hose.
Inspect the breather hose for possible kinks or wear. The
hose is form fitted for proper fit.
Follow the breather hose
q
from the crankcase fitting
w
to the airbox
e
.
IMPORTANT
Ensure hoses are not kinked or pinched.
MAINTENANCE
