12.4
9850045 R01 - 2020-2021 RANGER 1000 Service Manual
© Copyright Polaris Inc.
BODY ELECTRICAL SPECIFICATIONS
PART DESCRIPTION
SERVICE
SPECIFICATION
Seat Belt Switch Normally Open
Drive Mode Switch -
Performance
4750 Ω
Drive Mode Switch -
Standard
25,000 Ω
Drive Mode Switch - Work 1600 Ω
AWD Hub Coil Resistance 24 Ω ± 5%
Current Draw - Key Off
(Max)
.01 DCA (10 mA)
Stator Output 660 (900 Factory
Choice) Watts @ 3000
RPM
Stator Leg to Leg
Resistance
Less than 1 Ω
Stator Leg to Ground
Resistance
Open Line (OL / ∞)
Stator Leg Voltage (1300
RPM)
21 VAC ± 25%
Stator Leg Voltage (3000
RPM)
47 VAC ± 25%
Stator Leg Voltage (5000
RPM)
79 VAC ± 25%
Starter Solenoid Terminal
Resistance (77 °F)
2.5 Ω ± 20%
Parking Brake Switch Normally Open
CHASSIS / BODY ELECTRICAL
