12.7
RELAY OPERATION
Located in the fuse box under the passenger seat, the
relays assist with component operation like the cooling
fan, fuel pump, EFI system, drive system and EPS.
NOTICE
The Rear Diff Solenoid Relay is mounted separately,
attached to the rear portion of the main frame and can
be accessed by tilting the rear cargo box.
CHASSIS RELAY provides power to the following
systems:
• Lights (Headlights / Taillights)
• Drive (AWD / TURF)
CHASSIS RELAY
COLOR FUNCTION
Red
BUSS Bar - 12 Vdc constant
battery voltage (fusible link
protected).
Brown / White
Relay coil ground.
Orange
12 Vdc power input from key
switch to enable relay.
White
Provides 12 Vdc power for lights,
drive and accessory circuits.
ACCESSORY RELAY provides power to the following
systems:
• Accessories: 12V Receptacles & Accessory options
ACCESSORY RELAY
COLOR FUNCTION
Orange/White B+ Accessory Fuse Out
Brown Ground
Orange/White
B+ ACC Fuse out
Orange R/S B+ Accessory Relay
EFI RELAY provides power to the following systems:
• Fuel Injectors
• Ignition Coil
• Fan Relay
• Fuel Pump Relay
• Brake Pressure Switch
• Seat Belt Switch
• Purge Solenoid
• Chassis Relay
EFI RELAY
COLOR FUNCTION
Red / White
20-Amp fuse protected 12 Vdc
constant battery voltage.
Dark Green /
Yellow
ECU ground input to enable
relay.
Red / White
20-Amp fuse protected 12 Vdc
constant battery voltage.
Red / Dark Blue
Provides 12 Vdc power for EFI
system circuits.
