Polaris RANGER 1000 2020 - Differential Solenoid Replacement

12.22
9850045 R01 - 2020-2021 RANGER 1000 Service Manual
© Copyright Polaris Inc.
DIFFERENTIAL SOLENOID REPLACEMENT
1. Disconnect the wire harness from the solenoid.
2. Remove the nut
q
holding the solenoid to the
transmission.
3. To install, reverse the removal procedure. Torque the
solenoid fastener to specification.
TORQUE
Differential Solenoid Nut:
25 ft-lbs (34 N·m)
CHASSIS / BODY ELECTRICAL
