ENGINE SERVICE - TOP END
VALVE COVER SERVICE
REMOVAL
1. Disconnect the spark plug wire retention clip from the
valve cover.
2. Remove the five fasteners
q
and isolators
w
securing the valve cover
e
to the engine. Remove
the valve cover.
3. Remove the valve cover gasket
r
and discard.
INSTALLATION
1. Install a new valve cover gasket
r
.
IMPORTANT
Ensure the gasket is fully seated in the valve cover
groove.
2. Install the valve cover
e
on the engine.
3. Install the fasteners
q
and new rubber isolators
w
.
ENGINE / COOLING / EXHAUST
