HEADLINER SERVICE
REMOVAL
1. Remove the two rear push rivets.
2. Remove the five push rivets securing both headliners
to the windshield plate.
3. Remove the rear headliner.
NOTICE
If equipped, removing the dome light may ease removal
of the headliner. This can also prevent damage to the
headliner and dome light.
4. Remove the two T30 fasteners from the front
headliner.
5. Remove the front headliner.
