4.20
9850045 R01 - 2020-2021 RANGER 1000 Service Manual
© Copyright Polaris Inc.
SPARK PLUG
SPARK PLUG INSPECTION
• Inspect the insulation
q
for signs of cracking or
chipping. Replace if any is found.
NOTICE
Cracks can be difficult to see. Any cracking on the
insulation can lead to a drivability concern.
• Inspect the ground electrode
w
for signs of wear or
irregular engine conditions. Verify the electrode gap is
correct.
SPARK PLUG SERVICE
REMOVAL
1. Disconnect the ignition coil retention clip from the
valve cover.
2. Remove the MAG spark plug wire
e
and PTO spark
plug wire
r
.
ENGINE ELECTRICAL
