FUEL VENT LINE ROUTING
The fuel tank is vented through a vent line. The vent line is routed from the fuel tank underneath the driver seat and
secured into a vertical section of the frame with a vent line termination fitting.
NOTICE
Image orientation is from the front driver-side of the vehicle
