EXHAUST HEAT SHIELD INSPECTION
IMPORTANT
Inspect Exhaust Heat Shields and make sure they are in good condition and are secured properly.
ITEM DESCRIPTION NOTE
q
Closeoff Shield
w
Lower Headpipe Shield Overlaps under the Upper Shield
e
Inner Silencer Shield
r
Outer Silencer Shield
t
Inner Headpipe Shield
y
Upper Headpipe Shield Overlaps over the Lower Shield
