FUEL LINES
FUEL LINE ROUTING
• The fuel line is routed from the fuel tank to the fuel rail on the engine. It is secured to the engine breather hose, inner
clutch cover and clutch duct with retention clips.
NOTICE
Image is from top looking down.
